2.145 MW Co-generation Plant

Manufacturer: MTU
Model: GB 2145 N5
Year: 2011

1 MTU Genset

• Model GB 2145 N5
• 2145 kW
• 0.8 Power Factor
• 400 Volts
• 50Hz
• Year: 2011

1 MTU Gas Engine

• Model 20V 4000 L63
• 2,200 MWm/2,145MWe
• 1500rpm
• 20 Cylinders
• Year: 2011

1 Stamford Generator

• Model LVSI804T2
• 2800kVA
• 400VAC
• 4041.5A
• 1500rpm
• 50Hz
• Star Connection
• H Insulation Class
• IP 23 Protection Class
• Year: 2011

1 ABB Transformer

• Model TSPH-11121/900
• 2500kVA
• ONAN Cooling Type
• 3 Phase
• Voltage
• 1. Stage 28,500
• 2. Stage 30,000
• 3. Stage 31,500 – 400
• 4. Stage 33,000
• 5. 34,500
• 50Hz
• YND11 Vector Group
• YG 170/70 and AG -/3 Insulation Level
• 5.98% Short Circuit Voltage
• 45.82/3609 Current

1 Hilkar Neutral Grounding Resistor

• Model NTD.XL.1.20
• 31.5/ kV
• IP23 Protection Class
• Year: 2011

1 Friterm HT Radiator

• Model FYKS 8025 D 2/3 2/2.1
• 1338.41 kW
• 18kW Total Power
• 400V AC 3Ph 50Hz
• 13 Bar Maximum Operating Pressure
• Year: 2011

1 Friterm LT Radiator

• Model FYKS 8025 D 2/3 2/2.1
• 158.6kW Capacity
• 18kW Total Power
• 400V AC 3Ph 50 Hz
• 13 Barg Maximum Operating Pressure
• Year: 2011

1 Segu Muhendislik S.S. Waste Heat Recovery System

• Model Heat Recovery Steam Generator
• 855kW Maximum Capacity
• 175C Operating Temperature
• 179.9C Design Temperature
• 8 Barg Operating Pressure
• 9 Barg Design Pressure
• 13. Barg Test Pressure
• Year: 2011
• Model STB9/I/1600/NR

2 Segu Muhendislik A.S Economizer

• 110kW Capacity
• 105/165C Operating Temperature
• 179.9C Design Temperature
• 8 Barg Operating Pressure
• 9 Barg Design Pressure
• 13.5 Barg Test Pressure

1 Hot Water Circulation Pump

• MOTOR: Manufacturer Siemens
• Model UD 1106/1338162-0169-14
• 11kW

PUMP

• Manufacturer Grundfos
• Model A96087516P212090002 1

1 LT Water Circulation Pump

• MOTOR Manufacturer Siemens
• Model 87420021
• 11kW

PUMP

• Manufacturer Grundfos
• Model A96109

1 Alfa Laval HT Heat Exchanger

• Model M6-MFM
• 10 Bar Design Pressure
• 13 Bar Test Pressure
• Year: 2011

1 Alfa Laval LT Heat Exchanger

• Model M10-MFM ALG
• 13 Bar Test Pressure
• Year: 2011

Contact for Pricing
